PL332 GPS Digital Capacitance Level Sensor Anti Fuel Theft

    Buy cheap PL332 GPS Digital Capacitance Level Sensor Anti Fuel Theft from wholesalers

    Buy cheap PL332 GPS Digital Capacitance Level Sensor Anti Fuel Theft from wholesalers
    • Buy cheap PL332 GPS Digital Capacitance Level Sensor Anti Fuel Theft from wholesalers

    PL332 GPS Digital Capacitance Level Sensor Anti Fuel Theft

    Ask Lasest Price
    Brand Name : Atech
    Model Number : PL332
    Certification : CE,RoHS
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 10000 pcs month
    Delivery Time : 5-8work days
    • Product Details
    • Company Profile

    PL332 GPS Digital Capacitance Level Sensor Anti Fuel Theft

    PL332 Anti Fuel-Theft GPS Digital Capacitance Level Sensor

    The PL332 sensor series uses capacitance as the sensitive element to continuously detect the oil level with a resolution of 1mm. The sensor length can also be shortened to accommodate tanks of different heights. With a wide range of voltage input and easily adjustable length, the PL332 is easy to set up and suitable for a wide range of applications.

    Applications

    1.Brass nickel-plated material is strong and durable Fix the cable to prevent disconnection

    2.Reduce oil rod damage caused by the impact of oil tank shaking on the bumpy road section

    3.Comes with 5 M5 screws and 2mm thick rubber NBR gasket Completely prevent gasoline penetration and corrosion Simple installation and convenient maintenance

    4.Strong and oil-resistant, flame-retardantRed: positive powerBlack: negative powerBlue: output (0-5V, 0.5-4.5V, RS232, RS485)

    Feature of water capacitive level sensor

    1. Light weight and low cost

    2. Length can be customized

    3. Without limitation of environment

    4. Long using life, wear resistance

    Specifications

    Material
    Aluminum alloy
    Length range
    Installation
    SAE standard 5 holes
    Flanges
    Various types of flanges are available for fitting fuel tank if necessary
    Mounting

    5 pieces of M5 screws and 2 mm thick NBR gasket,

    or recommended 2 mm thick FPM gasket if be used in gas tank.

    Supply voltages
    10 to 32V
    Rated current for switch
    500mA
    Output signal
    0 to 5V (Voltage)
    RS232
    RS485
    Operating temperatures
    Protection rank IP65
    Resolution 1mm

    PL332 GPS Digital Capacitance Level Sensor Anti Fuel Theft

    PL332 GPS Digital Capacitance Level Sensor Anti Fuel Theft

    We have the 0-190ohm/240-33ohm , the length of sensor can customize, if you need other signal and length, if you need wholesale or dropping shipping, welcome to contact to us.we support all wholesale and drop shipping.
