Feature
● Wide range application
● Long service life
● Diffused silicon oil-filed sensor cell
● CE certificate
● Reinforcement cables optional
● Intrinsically sate ,explosion proof
Applications
● Hydraulic monitoring
● Frequency water supply
● Liquid measuring for petroleum ,metallurgy
● City water supply
● Sewage treatment
● Tank level monitoringT
● Water-saving irrigation
● Circulation fluid monitoring
Description
PL301 series fuel oil level sensor adopts high performance diffused
silicon piezoresistive pressure sensor as the measuring element
series pressure transmitter is a high reliability, high stability,
high accuracy and small volume level transmitter with part
structure. Widely used in measurement liquid pressure and height in
small inside diameter pump as well as level height of liquid
reservoir, such as water, oil and mild corrosive liquid.
We offer special ventilate cable that resistance to abrasion, oil,
acid & alkaline and strength according to on-site environment.
PL301 has got intrinsic safety certification, explosion proof
certification and CE certification.
After long-term aging time, PT301 has stable and reliable
performance, It can adapt to the harsh environment outdoors.
Speifications
| pressure medium | liquid compatible stainless steel |
| pressure ranges | 0~0.5 m H2O...500 m H2O |
| overload pressure | 150%FS |
| output signal | 4~20mA, 0.4 ~4.5V, 0~5V, RS485, RS232, 868 Mhz |
| accuracy | 0.5%FS (standard) |
| load resistance | RL = (U-10)/0.02(Ω) (4~20mA current output), ＞20KΩ (voltage output) |
| long term stability | 0.2%FS/year |
| supply voltage | 24VDC ,12VDC |
| compensated temperature range | -40~85°c |
| operating temperature range | 0~+85°c |
| storage temperature range | -40~+85°c |
| temperature coefficient of zero | 1.5%FS (Max) |
| temperature coefficient of span | 1.5%FS (Max) |
| insulation resistance | 100MΩ@ 250VDC |
| Pressure connection | screw thread, throw-in type |
| Protection grade | IP68 |
| material of wetted part and housing | 1Cr18Ni9Ti |
| material of pressure membrane | 316L |
| Response time | 1ms |
FAQ
1.Q: How long is the delivery?
-- Mostly within 10days
2.Q:Can I get a sample?
-- Sure, contact our sales please
3.Q:What is your MOQ?
-- 1pcs
4.Q: How about warranty time?
-- 12-18month
5.Q: How can I visit your factory?
-- Fly to Xian Yang air port, it’s our pleasure to pick you up.
6.Q:How do you control your quality ?
-- We have EPR system .we control from parts, process, testing,
packing ,retesting.
Every Sensor will be tested two times before reach you, after that
sport test for the third time. Make sure about the quantity.
Ordering guide:
In order to recommend the suitable sensor, please kindly advise us
the following information
1..What is your testing medium ? oil, water, gas, waster water, or others.
2.Working temperature of the sensor ? -40°C~100°C or others
3.Pressure range ? -1-0bar,0-1bar,0-16bar,0-40bar,0-100bar,0-600bar or others
4.Output signal? 4-20mA, 0-5V ,0.5-4.5V,0-10V,RS485 or other
5.Electronic connection ? DIN43650 ,Packard, Aerial plug, direct cable or others.
6.Screw ? M20×1.5,G1/4,G1/2,R1/2,NPT1/2
